| General | |
| Frequency Range | UHF1:400-470MHz,UHF3:350-400MHz,UHF5:806-941MHz; VHF1:136-174MHz |
| Channel Capacity | 1024 |
| Zone Capacity | 64 (maximum of 256 channels per zone) |
| Channel Spacing | 25/20/12.5KHz |
| Operating Voltage | 7.4V |
| Battery | 2000mAh (Li-Ion) 2500mAh (Li-Ion) 3000mAh (Li-Ion) |
| Battey Life(5/5/90 Duty Cycle,High TX Power) | Analog/Digital: 14.5hours/19.5hours (2000mAh) 18hours/24hours (2500mAh) 21hours/27hours (3000mAh) |
| Frequency Stability | ±0.5ppm |
| Antenna Impedance | 50Ω |
| Dimensions(H×W×D) mm | 131 × 54.5 × 36（2000mAh）; 131 × 54.5 × 41（2500mAh）; 131 × 54.5 × 41（3000mAh） |
| Weight | 361g (2500mAh); 366g (3000mAh); 350g (2000mAh) |
| Display | LCD Display:160×128 pixel，65536 colours，1.8 inch，6 rows |
| Receiver | |
| Sensitivity(Analog) | 0.28μV(12dB SIN AD); 0.22μV(typical)(12dB SIN AD); 0.4μV(20dB SIN AD) |
| Sensitivity(Digital) | 0.22μV/BER 5% |
| Rated Audio Power Output | 0.5W |
| Transmitter | |
| RF Power Output | UHF1/UHF3: 1W/4W; VHF1: 1W/5W; UHF5: 1W/2.5W |
| Digital Vocoder Type | AMBE+2™, NVOC 或 SELP |
| Environmental | |
| Operating Temperature | -30℃～+60℃ |
| Storage Temperature | -40℃～+85℃ |
| ESD | IEC 61000-4-2（level 4） ±8kV（Contact） ±15kV（Air） |
| Dust & Water Protection | IP68 |
| Humidity | MIL-STD-810 C/D/E/F/G |
| Vibration,Drop&Shock | MIL-STD-810 C/D/E/F/G |
| GPS Specifications | |
| Horizontal Position Accuracy | <5m |
| Cold Start (Time to First Fix) | <1 minute |
| Hot Start (Time to First Fix) | <10 seconds |
| Note | Accuracy Specs are for long-term tracking(95th percentile values>5 satellites visible at a nominal-130dBm signal strength) |
